UVIN-12109-P4

[UV-NVR, 12MP, 9CH, 80Mbps, 1HDDs, 4POE]

  • 9ch real-time recording & playback simultaneously
  • 4 PoE Ports
  • 80Mbps recording bandwidth
  • Max. 12M IPC input / 4K output(HDMI) & VGA
  • Support ONVIF Profile S
  • Support H.264, H.265 Dual Codec
  • 1 internal SATA HDD (Max 10TB)
  • Audio I/O 1/1
  • Plug & Play With SMD, Intrusion Detection, Line Crossing Detect Area, Loitering Detection, People Gathering Detection, Ilegal Parking, Face Detection
  • Support Remote DVR (Remote DVR/NVR control)
Categories: ,

Description

System
Main Processor Dual Cortex A53
Operating System Embedded LINUX
Video
Input 9CH(12MP/8MP/6MP/5MP/4MP/3MP/1080p/1280×1024/960p/720p/D1/CIF)
Output 1*HDMI,1*VGA
Audio
Input 1 Port RCA, support 16CH IPC audio input
Output 1 Port RCA(Linear, 1kΩ), HD output
Audio Bit Rate 64kbps
Audio Compression standard G711U, G711A
Intercom support (two-way)
Alarm
Sensor Input N/A
Output N/A
Motion Detection 9 Channel, MD Zones: 396 (22 × 18)
Trigger Events Recording, Email, FTP, Snapshot and Screen Tips
Display
HD Output1 4K(3840*2160)/2K(2560*1440)/1920*1080/1280*1024/1280*720/1024*768
HD Output2 N/A
VGA 1920×1080, 1280×1024, 1280×720, 1024×768
Display Split 16CH/13CH/10CH/9CH/8CH/6CH/4CH/1CH
Digital Zoom YES
OSD Camera Title, Time, Recording, Motion Detection, Event Alarm
Recording
Video Compression H265/H264/H265+/H264+
Resolution 12MP(4000*3000),8MP(3840×2160),6MP(3072*2048),5MP(2592×1944),4MP(2688×1520/2560×1440)

3MP(2048×1536),1080P(1920×1080),1280×1024,960P(1280×960),720P(1280×720),960H(960×480)D1(720×576/720×480)
Record Rate PAL: 12MP@10CHx25fps,4K@16CHx25fps,5MP@16CH×25fps, 4MP@16CHx25fps,

3MP@16CH×25fps,1080P@16CH×25fps, 960P@16CH×25fps,720P@16CH×25fps, D1@16CH×25fps
NTSC: 12MP@10CHx30fps,4K@16CHx30fps,5MP@16CH×30fp,4MP@16CH×30fp,

3MP@16CH×30fps,1080P@16CH×30fp,960P@16CH×30fp, 720P@16CH×30fp,D1@16CH×30fp
Record Mode Manual\Timer\Motion Detection\Smart Event
Playback & Backup
Local Sync Playback 1CH 12MP@30fps,1CH 8MP@30fps,2CH 5MP@30fps,4CH 4MP@30fps,7CH 1080P@30fps,16CH 720P@30fps,16CH D1@30fps
Decode Capability 1080P(1920×1080)@210fps
Remote Sync Playback YES
Search Mode ALL, Timing Video, Motion Detection, Tag  search,Smart Event,Pictrue,Log
Playback Functions Play, pause, fast forward, rewind, previous frame, next frame, electronic zoom, clip, audio
Backup Mode USB Device/Network
Network
Interface 1 RJ45(10M/100M/1000M self-adaptive Ethernet Interface)
Incoming Bandwidth 80Mbps
Outgoing Bandwidth 80Mbps
Network Functions IPv4/IPv6/TCP/IP, HTTP,HTTPS, UPnP, DNS, NTP, SMTP, DHCP, FTP, DDNS, RTSP, RTCP, p2p,PPPOE
Onvif Profile S, Profile T
Web Browser Edge,IE8-11, Google Chrome , Firefox ,Safari
CMS Software Support  Windows 7/ Windows 8/Windows 10/Windows 11/MAC OS
Cloud Support Yes
Smart Phone iPhone,  Android
POE 4 x Independent 100Mbps POE Network Interfaces(Output Power AT mode 30W per Interface, AF mode 15W per Interface), 45/78 line order, Total Power Output 72W,  Support Plug and Play, Support network cable extended mode Max. 200M
WIFI N/A
Storage
Interface Type 1 SATA Hard Disk Interface (3.5″ SATA)
Capacity Up to 10TB capacity
eSATA N/A
General
Language  UI Simplified Chinese, Traditional Chinese, English, Polski, Czech, Russian, Arabic, German, French, Portuguese, Spanish, Italian, Hungarian, Korean, Dutch, Greek, Janpanese, Ukrainian, Kazakh
USB Interface 2 USB 2.0 Interfaces
RS485 N/A
Power consumption DC48V/1.87A  ≤ 10W (Without Hard Disk)
Working Environment -10℃～50℃, 10%～90%(humidity)
Product Dimension(W×D×H) 260*230*43(mm)
Net Weight 1.01kg(without HDD)
Gross Weight 1.75kg(without HDD)
